Product overview

• Our own designing desktop reader MR6061U is built-in antenna and a?Type of small size desktop read & write device, it can read & write many?Different kinds of UHF tags, maximum reading range about 10cm.?Full compatible with EPC Gen 2 and ISO180006B Protocol Compact size, read & write capability?Connect PC via USB port, draw power from PC USB?Function of “write with password”

Product parameters

• Model?MR6061U
• Support Protocol?EPC Gen 2(ISO18000-6C)?ISO18000-6B
• Working Frequency?ISM902~928MHz?ISM865~868MHz
• Working Mode?FHSS
• RF Power?10dBm
• Reading Speed?Software programmable, Single card averagereading each 64Bits less than 10ms
• Data Interface?USB
• Read Method?Command Mode, application software?Command control write card
• Reading Range?≤10cm circular polarization antenna
• Reading Indication?Buzzer, LED
• Antenna?Built in small circular polarization antenna
• Power Adapter?PC USB Power Supply
• Dimension?104*68*10mm
• Operation Temp.?-10℃~+60℃
• Storage Temp.?-15℃~+65℃
• Weight?0.1KG
